Android 9.0 System Navigation Video Interface box For new generation Mazda series with connect system
Optional with joystick control Carplay, Touch screen, Wi-Fi, BT, Mirror Link, Cast screen, HD 1080P, Google MAP, Play Store, Voice control
Please check if your cars could be compatible or not before order!
For dealer customer:
1. all UI you see could be made specially for you, need MOQ 100pcs
each month.
2. The logo and the lable of machine could be made specially for
you.
3. OEM is supported.
Solution we have for:
- Mazda CX-30 2019-present
- Mazda 3 2019-presen
Brand: Lsailt Model: LLT-MZD-VER6.6.5
Standard Configuration: Video Interface (Trajectory Reversing,Front View,Video Input)and
Android Navigation Box;
Suitable car model: For 2019 or later Mazda 3, CX-30
Upgrading Function: Touch Android Navigation System, Trajectory Reversing, Front View,
DVD, TV, 360 Panoramic, DVR, TPMS etc.
Android’s features:
1. Android 9.0 system, maxmium 3+32GB storage 6 core 1.2GHz chip.
2. Compatible all Android apps include YouTube, Waze, Google map, Yandex navi Real-time & offline
navigation etc, free download from Google Play store.
3. Operate whole system by Mazda origin shift knob touch screen on central console, optional touch screen.
4. Compatible to car origin rear view & front view, DVR, 360 panorama, TV box, TPMS optional.
5. ADAS lane monitoring is supported with DVR optional.
6. Connect via Wi-Fi Bluetooth USB.
7. Could be switch to origin system with just one click on
dashboard or steering wheel.
8. Voice activate navigation, mirror link.
9. Simple plug & play installation.
10. Multi languages are supported, include English Pусский Français Español Português Arabic Persian Japanese Korean
Hebrew etc
11. Optional Apple Carplay with extra Carplay module, control by Mazda original joystick(need an iPhone later than iPhone 5 with iOS9 or above system)
Professional festures & hardware
1. Multi screen interactive display is supported, LVDS out put.
2. Accessories like rear view, 360 bird eye camera box, DVD, DVB-T
TV box, DVR, mirror link, video play via USB.
3. Support 2 HD RGB & LVDS video signal input.
4. 1080P video play supprted.
5. Voice control navigation from both factory MIC or ours.
6. Adaptive Display definition .
7. Touchscreen interface: Support 4-wire resistive & capacitive
touch layer
8. Support MCU wireless system update
Model: LLT-MZD-VER6.5.3/5
| Resolution | adaptive |
| Display | LVDS Digital |
| SYSTEM: | Android OS 9.0 |
| RAM: | 3GB |
| ROM: | 32GB EMMC |
| CPU MODEL | T7 |
| WIFI: | Support |
| Bluetooth: | Support |
| MirrorLink: | From Android smartphonr & iPhone |
| Microphone: | Include |
| TF Card : | For Map data |
| Play Store: | Support |
| Youtube: | Support |
| AV IN: | DTV and AV1 |
| Video OUT: | V and V1 |
| Installation Method | Plug and Play |
