4+64GB CarPlay/Android Interface included HEMA, NetFlix Spotify for
Alphard Toyota Camry
Product Descriptions
It’s a multimedia interface box without monitor.It integrates to
OEM screen and radio.Lsailt interface is connected to the plugs
behind of monitor without interfering with the head unit. With this
module, it is possible not only to use Yandex, Netflix , YouTube
,Navigator or Navitel with traffic jams in real time, but also to
play videos, download applications and use USB drives. The Android
interface box supports to connect additional equipment to the car
through itself: various audio and video devices, a front view
camera 360 cameras.
Hardware Specifications
TF Card slot: support 64GBMaximum (Parcel not include TF Card)
AV IN: AV
USB Port: 3 USB (USB0: used to connect CarPlay and Update OS,USB1:
used to connect ADAS. USB2:Media Player)
HDMI OUT: Support 720P
Camera/AHD: 4 CAM input(guideline )
GPS Module: GPS and Beidou dual-mode GPS (BDS/UBLOX)
Special Function
MCU and APP : Online upgrade via WIFI
Cold start Time: 30 seconds
Hot Start: 6 seconds
Sleep: Yes(Cycle 5 times and restart once)
Sleep memory: Memory parking operation last APP
Installation Method: Plug and Play
Media Control
Microphone: Use OEM microphone
Steering Wheel:can use up and down song, Vol DisPlay buttons
Forced Reset: press MODE for 6 seconds
Features
1.Included CarPlay and Android Auto
2.Included YouTube/Netflix/Waze/Google map/Waze...
3.Included HDMI OUT/LVDS IN/ AV IN
4.Support split screen
5.Support MCU online upgrade
6.Support OEM buttons/touch screen/steering wheel operate
7.Support factory/OEM cameras
8.Five kinds of UI for optional in setup.
9.Supports multilanguages : English , Russian ,Arabic , Spanish,
Hebrew, Korean, Japanese....
10.Enable to download apps from play store.
11.Android/IOS phone mirroring to OEM screen via Wi-Fi or USB cable
through CarPlay/Android Auto.
12. Online-map: Google map , waze,HEMA...
13. Support factory and additional cameras.
14. Video inputs for adding Reverse camera , front camera , 360
panorama cameras.....
15. Video out for headrest monitor
16. Connect network by Wi-Fi or SIM car via 4g USB dongle.
17. Bluetooth for hands free answer phone and OBD show information
on dashboard.
18. Plug and play simple installation
Optional Devices
· ---USB ADAS/DVR
· ---TV Module
· ---DVD Module
· ---reverse camera
· --360 Panorama cameras
What’s ADAS?
ADAS is a simple device connected by USB cable. It included the
function of the DVR and comes with a camera to record the videos
during driving. Besides , it will warm the driver when the car it
too closed to the front car . It will warm when the car departure
the lane also.
Specifications:
| Android Version | Android 9.0 |
| Processor | PX6 RK3399 |
| RAM | 4GB |
| ROM | 64GB |
| CarPlay | Included |
| Android Auto | Included |
| Mirror Link | Included |
| Video input | LVDS |
| WiFi | Included |
| Bluetooth | Included |
| Play store | Included |
| TF card slot | Included |
| AV input | included for DTV |
| HDMI output | Included for headrest monitor |
| Cameras | Support factory and after-market cameras(guideline and radar) |
| Low power comsumption after car off | support |
| pin to pin installation | support |
| Mircrophone | support |
| Steering wheel Control | support |
| OEM buttons control | support |
| OEM touch screen control | support |
Quality warranty policy:
3 month free replacement and 1 year free maintenance due to product
problem . Send goods in 1 or 2 days after full payment received.
Customer service department will contact with you by whatsapp,
email, skype for after-sale service .
