Car Android Navigation System Video Interface box For Chevrolet Malibu Suburban Tahoe Silverado GMC Yukon Sierra etc (Cadillac CUE SYSTEM
Chevrolet Mylink system Buick Opel intellink system)
Android’s features:
1. Android 6.0 system, 2+16GB storage Quad core 1.2GHz chip.
2. Compatible all Android apps include YouTube, Waze, Google map, iGO, Yandex navi Real-time & offline
navigation etc, free download from Google Play store.
3. Operate whole system by Chevrolet origin touch screen on central console.
4. Compatible to car origin rear view & front view, DVR, 360 panorama, TV box, TPMS optional.
5. ADAS lane monitoring is supported with DVR.
6. Connect via Wi-Fi Bluetooth USB.
7. Could be switch to origin system with just one click on
dashboard or steering wheel.
8. Voice activate navigation, mirror link.
9. Simple plug & play installation.
10. Multi languages are supported, include English Pусский Français Español Português Arabic Persian Japanese Korean
Hebrew etc
Professional festures & hardware
1. Multi screen interactive display is supported, LVDS out put.
2. Accessories like rear view, 360 bird eye camera box, DVD, DVB-T
TV box, DVR, mirror link, video play via USB.
3. Support 2 HD RGB & LVDS video signal input.
4. 4K video play supprted.
5. Voice control navigation from both factory MIC or ours.
6. Display definition 480*800.
7. Touchscreen interface: Support 4-wire resistive & capacitive
touch layer
8. Support MCU wireless system update
| Resolution | 800X480 |
| Display | LVDS Digital |
| SYSTEM: | Android OS 6.0.1 |
| RAM: | 2GB |
| ROM: | 16GB EMMC |
| CPU MODEL | T3 |
| WIFI: | Support |
| BT: | Support |
| MirrorLink: | From Android smartphonr & iPhone |
| Microphone: | Include |
| TF Card : | For Map data |
| Navi Sound | Coming from added speaker |
| Play Store: | Support |
| Youtube: | Support |
| MCU and APP Update: | System update via wifi to Internet |
| AV IN: | DTV and AV1 |
| Video OUT: | V and V1 |
| Camera: | Front/Left/Rear/Right (flexible guideline and radar ) |
| Cold start Time: | 40 seconds |
| Hot Start: | 6 seconds |
| Sleep: | Yes(Restart once after 5 times cycle sleep) |
| Sleep memory | Remember Last active APP |
| Switch Mode: | Press and hold the house button for 3 seconds |
| Use Operation: | By Origin car Touch |
| Steering Wheel: | Support sound track & volume adjustment |
| Forced Reset | PWR button(Long press 5 seconds) |
| Original Car Onstar in Android: | Automatically back to the original car, waiting for 10 seconds back
to Android |
| Speed Control: | All cameras are effctive under 20 km/h |
| Installation Method | Plug and Play |
Competitive advantages
1.Convenient installation,all on the plug;DO not destroy the
original vehicle lines,simple operation;
2.Random installation,without secondary installation;
3.Simple functions,strong stability,more useful;
4.Convenient to upgrading map;
5.Android:Internet access,HD video playback,full audio format,voice
search,comes with WIFI,Real-Time traffic
Navigation,arbitrary,automotive Android phone.
6.Why not produce all-in-one machine? Because Android system heat
badly.To prevent against crashes,break down,we produce split to
work more better and stable.
| Function Parameters Andrews |
| Internet |
| WIFI | After good Wi-Fi connection,select the current can be connected
Wi-Fi hotspots,enter the password to connect to the Internet after
the Internet
Via your 3G/4G mobile phone can also be used as hot provide
navigation hosts (this set with reference to your mobile phone
manual) |
| 3G | 3G/WCDMA/CDMA2000/TD-SCDMA standard |
| Support surf the Internet through 3G USB dongle or 3G mobile share
next work |
| MAP (GPS Navigation) |
| Supportable navigation software | Beauty line,DaoDaoTong,LingTu,
hypergraph,NaviOne,AutoNavi,baidu,Google,IGO,SYGIC |
| Map Upgrading | Through TF card |
| Support 3D live navigation,(Need navigation software to support) |
| Support navigation sound mixing/sound sent back |
| Support real-time traffic(Need navigation software to
support,internet) |
| Support multiple navigation software |
| Task Manager |
| Functions | Support the task list of activities |
| Support to switch the activities task |
| Support to close the activities task |
| System with Google | The browser,calculator,calendar and send E-mail,Google store |
| Software Upgrading | TF or U flash disk |
| Voice Recognition | Support |
| System Language | Multi language |
