Chevrolet Malibu mirror link android Video Interface box WIFI cast
screen origin mylink system
Car Android Navigation System Video Interface box For Chevrolet Malibu (MYLINK SYSTEM) Upgrade Touch screen Navigation, WIFI, BT, MirrorLink, HD 1080P, Google MAP, Play Store, Voice
Based on Android system, the Andorid system box can do almost
everything you can imagine in the car, all android application
include google map, youtube, facebook, twitter, tumblr, web
browsing etc, the rearview, 360 degree sight view, data video
record etc.
You can even control the screen via your smartphone, both Android &
iOS device is supported, mirrorlink.
Product Information
| Origin | Shenzhen | Trademark | Lsailt |
| Product Model | LLT-KDLK-VER3.8.3 | Standard | CCC,CE |
| Type | Android Navigator Interface | Use | Automotive |
Android’s features:
1. Android 6.0 system, 2+16GB storage Quad core 1.2GHz chip.
2. Compatible all Android apps include YouTube, Waze, Google map, iGO, Yandex navi Real-time & offline
navigation etc, free download from Google Play store.
3. Operate whole system by Chevrolet origin touch screen on central console.
4. Compatible to car origin rear view & front view, DVR, 360 panorama, TV box, TPMS optional.
5. ADAS lane monitoring is supported with DVR.
6. Connect via Wi-Fi Bluetooth USB.
7. Could be switch to origin system with just one click on
dashboard or steering wheel.
8. Voice activate navigation, mirror link.
9. Simple plug & play installation.
10. Multi languages are supported, include English Pусский Français Español Português Arabic Persian Japanese Korean
Hebrew etc
Professional festures & hardware
1. Multi screen interactive display is supported, LVDS out put.
2. Accessories like rear view, 360 bird eye camera box, DVD, DVB-T
TV box, DVR, mirror link, video play via USB.
3. Support 2 HD RGB & LVDS video signal input.
4. 4K video play supprted.
5. Voice control navigation from both factory MIC or ours.
6. Display definition 480*800.
7. Touchscreen interface: Support 4-wire resistive & capacitive
touch layer
8. Support MCU wireless system update
1.Apply to: Car Android Navigation System Video Interface box For
Cadillac ATS, XTS, SRX, CTS, XT5, Chevrolet malibu Impala Suburban
Tahoe Traverse Equinox(Car CUE mylink SYSTEM) Upgrade Touch
Navigation,WIFI,BT, MirrorLink,HD 1080P,Google MAP, Play
Store,Voice
| Resolution | 800X480 |
| Display | LVDS Digital |
| SYSTEM: | Android OS 6.0.1 |
| RAM: | 2GB |
| ROM: | 16GB EMMC |
| CPU MODEL | T3 |
| WIFI: | Support |
| BT: | Support |
| MirrorLink: | From Android smartphonr & iPhone |
| Microphone: | Include |
| TF Card : | For Map data |
| Navi Sound | Coming from added speaker |
| Play Store: | Support |
| Youtube: | Support |
| MCU and APP Update: | System update via wifi to Internet |
| AV IN: | DTV and AV1 |
| Video OUT: | V and V1 |
| Camera: | Front/Left/Rear/Right (flexible guideline and radar ) |
| Cold start Time: | 40 seconds |
| Hot Start: | 6 seconds |
| Sleep: | Yes(Restart once after 5 times cycle sleep) |
| Sleep memory | Remember Last active APP |
| Switch Mode: | Press and hold the house button for 3 seconds |
| Use Operation: | By Origin car Touch |
| Steering Wheel: | Support sound track & volume adjustment |
| Forced Reset | PWR button(Long press 5 seconds) |
| Original Car Onstar in Android: | Automatically back to the original car, waiting for 10 seconds back
to Android |
| Speed Control: | All cameras are effctive under 20 km/h |
| Installation Method | Plug and Play |
Product Accessories |
Host Interface | 1(standard configuration) |
Host Android | 1(standard configuration) |
LVDS IN | 1(standard configuration) |
LVDS OUT | 1(standard configuration) |
AV IN/OUT | 1(standard configuration) |
POWER Line | 1(standard configuration) |
ANT | 1(standard configuration) |
Specification | 1(standard configuration) |
Warranty card | 1(standard configuration) |
Microphone | 1(standard configuration) |
SPK | 1(standard configuration) |
Map card | 1(standard configuration) |
